Technical Overview
Sound power at max. speed (2010/30/EC)
62 dB
Maximum output air extraction
268 m³/h
Boost position air extraction
400 m³/h
Colour
Silver metallic
Material body
zinc plated
Built-in / Free-standing
Built-in
Width
60 cm
Highlights
Awards
Specifications
Width
60 cm
Colour
Silver metallic
Type
Built-in into the cabinet
Air circulation
Convertible
Total power of the motors
70 W
Number of speed settings
3-stages + intensive setting
Maximum output air extraction
268 m³/h
Boost position air extraction
400 m³/h
Sound power at max. speed (2010/30/EC)
62 dB
Sound power boost (2010/30/EC)
69 dB
Maximum output recirculating air
263 m³/h
Boost position output recirculating
353 m³/h
Sound power at max. speed (recirculation)
64 dB
Sound power boost (recirculation)
68 dB
Grease filter material
Washable aluminium
Total annual energy consumption
21.0 kWh/annum
Height of the appliance
203 mm
Width of the appliance
598 mm
Depth
290 mm
Height of the chimney
GENERAL.N_A mm
Minimum distance above an electric hob
430 mm
Minimum distance above a gas hob
650 mm
Diameter of air outlet
120 / 150 mm
No-return airflow flap
Yes
Length electrical supply cord
175 cm
Net weight
8.2 kg
Minimum width for installation
526 mm
Maximum width for installation
526 mm
Depth for installation
290 mm
1 / 0
climateControl sensor
No
iQdrive
Yes
Extremely silent appliances
No
Clean filter reminders
No
Boost position
Yes
Delay Shut off modes
Yes
Remote control
No
Type of lamps used
LED
Total power of the lamps
4 W
Color temperature
Neutral (3.500 K)
emotionLight Pro
No
Home Connect
No
Hob-based hood control
No
